ARRMA Outcast Bearing Replacement Example

A gritty wheel that will not spin freely is rarely just an annoyance on an ARRMA Outcast. It adds heat, makes the motor and ESC work harder, and can turn a straightforward bashing session into a stripped hub, worn driveshaft or premature diff problem. This ARRMA Outcast bearing replacement example shows a practical way to identify the failed bearing, verify the size and refit the assembly properly rather than replacing parts on guesswork.

The Outcast is built to take punishment, but bearings live in the firing line. Water, fine dust, grass, hard landings and overtightened wheel nuts all take their toll. Replacing one rough bearing promptly is usually cheaper and quicker than rebuilding the surrounding driveline later.

Before starting: identify the source of drag

Do not order bearings solely because a wheel feels rough. First remove the wheel and turn the hub by hand. A damaged wheel bearing often feels notchy, tight or inconsistent through one full rotation. There may be visible side play at the wheel, a crunching sound, or a dark ring of contaminated grease around the bearing seal.

If the hub turns smoothly with the wheel removed, inspect the wheel hex, wheel nut and tyre for contact. Then turn the centre driveline and check the opposite wheel. Drag can also come from a bent driveshaft, damaged diff output, packed debris behind the hub or a failing bearing inside the differential case.

This matters because a hub bearing and a differential bearing can share symptoms, but the repair path is different. A careful diagnosis prevents you from changing good bearings while missing the real fault.

ARRMA Outcast bearing replacement example: front hub

For this example, assume the front right wheel has developed noticeable roughness after wet running. The vehicle is clean enough to work on, the battery is removed, and the tyre and wheel are already off. Exact bearing sizes and quantities depend on the Outcast version and the position on the vehicle, so confirm the fitment for your specific model or measure the old bearing before buying replacements.

Start by removing the wheel hex and checking the drive pin. If the pin is bent, worn flat or missing, replace it. A damaged pin can create play that is easily mistaken for a bearing issue.

Next, remove the hardware needed to release the steering knuckle or hub carrier. Keep the screws organised by location. ARRMA hardware is designed for hard use, but using the wrong screw in the wrong hole can bottom it out, restrict movement or damage the plastic component. If your Outcast has accumulated dirt in the suspension arms and hinge-pin area, brush it away before dismantling further.

With the hub carrier free, slide the driveshaft stub axle out carefully. The bearings are generally pressed into their pockets in the hub carrier, one on each side of the bore. Avoid levering against the rubber seal with a screwdriver. That can distort the shield or scar the carrier bore, making the new bearing a loose fit.

A bearing puller is the cleanest method. Where access is limited, push the bearing out evenly from the opposite side using a driver that contacts the outer race only. If the bearing is seized by corrosion, apply controlled pressure and work patiently. Heating the plastic carrier is not usually necessary and can introduce more problems than it solves.

Once removed, inspect both bearings, not only the visibly rough one. Spin each between finger and thumb. A good bearing feels smooth and quiet with no obvious grittiness. If one has failed after a wet or muddy session, the other has experienced the same contamination and may not be far behind. Replacing the pair at that hub is normally the sensible approach.

Confirm size and fitment before fitting

The most reliable way to identify an RC bearing is by its internal diameter, outer diameter and width. Measure in millimetres with digital callipers, or read the markings on the bearing seal if they are still legible. Measure the old component after cleaning it, not while it is full of mud or dried grease.

For a bearing in a wheel hub, verify three things: the inner diameter must fit the axle cleanly, the outer diameter must seat squarely in the carrier, and the width must not leave the bearing proud of the pocket. A bearing that appears close in size is not close enough. Even a small dimensional difference can cause binding, unwanted play or a hub that will not assemble correctly.

Model-specific fitment is the quickest route where the Outcast version is known. Shopping by bearing measurement is useful for custom builds, older vehicles with mixed parts, or situations where a previous owner has fitted alternative hubs. At 888-RC, both routes are useful because correct fitment is the priority, not a vague description such as “ARRMA wheel bearing”.

Bearing seal type is also worth considering. Rubber-sealed bearings are generally the practical choice for an Outcast that sees wet grass, loose soil and regular bashing. They offer better resistance to contamination than open bearings, although no seal makes a bearing permanently waterproof. Metal shields can spin freely with low drag but are less suited to persistent mud and water exposure.

Install the new bearings without damaging them

Clean the hub carrier bore with a lint-free cloth before fitting the replacements. Remove sand, old grease and corrosion residue, then inspect the bore for cracks or deformation. A new bearing cannot compensate for a damaged carrier. If the bearing seat is loose, the bearing can spin in the plastic, create heat and quickly ruin both parts.

Press the first bearing into the carrier by applying pressure to its outer race. A suitable bearing driver, socket or flat tool with the correct diameter works well. Never press through the inner race when installing into a hub, as force is transferred through the balls and races. The bearing should go in straight and seat fully without excessive force.

Refit the stub axle, then install the second bearing in the same controlled way. Reassemble the hub carrier, steering link and driveshaft in the reverse order. Check that the driveshaft is properly engaged and that no boot, washer or spacer has been trapped. Refit the wheel hex and drive pin, then tighten the wheel nut securely without overtightening it.

Before reinstalling the wheel, rotate the axle by hand. It should feel smooth and free, with no metal-on-metal scraping and no obvious wobble. Once the wheel is on, lift the vehicle and spin it again. Compare it with the opposite side. A small amount of resistance from the driveline is normal; a wheel that stops immediately or feels notchy needs another look before the next run.

When the problem is not the wheel bearing

If fresh hub bearings do not restore smooth running, move inwards through the driveline. Check the driveshaft for a bent stub, worn universal joint or damaged spline. Inspect the differential outputs for play and make sure the suspension arm, steering link and hub carrier move without binding through their travel.

A common mistake is assuming that every rough wheel points to the outer bearing. On a hard-used Outcast, the inner diff bearings may also be contaminated or worn, particularly if the vehicle has run in deep water. A growling sound when turning the centre driveline, or resistance that remains after the hub is removed, points towards the gearbox rather than the wheel assembly.

It is also worth checking bearing preload created by assembly. A missing spacer, incorrectly seated bearing or overtightened fastener can load the bearing sideways. That produces heat and premature wear even when the part is new and correctly sized.

Make the repair last longer

Bearings are consumable parts on a high-power stunt lorry, but they should not become a regular post-run expense. After wet running, remove moisture and debris before storing the vehicle. Do not blast water directly into hubs and gearbox openings. A soft brush, compressed air used carefully and a dry cloth are more useful than simply putting a wet Outcast back on the shelf.

Check wheel play and free rotation as part of normal maintenance, especially after big impacts. Replacing a bearing at the first sign of roughness protects the more expensive parts around it. For frequent bashers, keeping a few correctly sized spares on hand means a failed bearing does not end a planned running session.

The best bearing replacement is the one that restores smooth movement without introducing a new fitment problem. Take the extra minute to measure, inspect the surrounding hardware and test the assembly before the next pack. Your Outcast will feel sharper for it, and the rest of the driveline will thank you.
